Key Features
● The machine consists of the control system, inverter core, cooling water tank, etc.●The equipment adopts a German Siemens PLC control system, EWM welding movement, Swiss Maxon motor, Omron relay, and other famous brand configurations. Precise control of various input and output signals.
● Using touch man-machine interface, fast switching between Chinese and English interfaces, color 10-inch touch screen, graphic and step interface design, easy to operate and easy to learn and meet the requirements of different venues.
●With functions such as parameter saving/printing, it can be operated with basic welding skills.
●Real-time monitoring of welding parameters such as current, voltage, and speed during the welding process to ensure the safety and efficiency of the welding process.
● A complete set of welding control power supplies, small size, lightweight(only 18 kg), convenient for on-site mobile high-altitude welding operations.
Parameter
|
Model |
A-200 |
|
Input Voltage |
220V±10% 50/60Hz |
|
Utilization factor |
100% at 120A |
|
Welding Current Range |
5-200A |
| Applicable pipe thickness |
≤ 3mm |
|
Protective function |
Over-voltage protection, overcurrent protection, leakage protection, arc failure protection, tungsten short circuit protection, and phase loss detection. |
|
Dimensions |
500*293*334mm |
|
Weight |
18 kg |
