1. Turn on the start switch.
2. Open the dust cover.
3. Move the cutting head down to about 10 mm height above the worktable.
4. Wait until the blue light is on.
5. Open the mobile phone APP.
6. Move the cutting head slowly or in jog mode to get a clear image.
7. Click to confirm the nozzle in the APP.
8. Complete the red light centering.
|
Processing Scenario |
Traditional Manual Calibration Method |
Laser Collimation Coaxial Instrument |
|
Calibration Accuracy |
≥0.3mm |
≤0.08mm |
|
Calibration Efficiency |
Low, relying on experience, requiring multiple dotting, observation, and debugging on the strip, time - consuming |
High, 3 steps to complete the whole - process calibration, and it can be completed in more than 1 minute |
|
Yield Performance |
The success rate of coaxiality is only about 85% |
The success rate of coaxiality is 100% |
|
Operation Difficulty |
High, requiring high experience for debugging personnel |
Low, the whole process is visualized, and newbies can get started quickly |
|
Safety |
There is a laser safety risk. Laser is emitted during debugging, which may damage eyes |
No laser safety risk, no laser emission required during debugging |
|
Equipment Adaptability |
Poor, the equipment is heavy and complex, and it is difficult to flexibly adapt to multiple devices |
Good, portable design, can flexibly adapt to multiple devices |
|
Intelligent Degree |
Low, lack of self - diagnosis system |
AI |
