Laser Collaborative RobotsBT006071

Brand:
$0.00 USD

Note: Different prices will be automatically shown above when you input different level quantity for each relevant specification. Once your quantity lies in “inquiry”, please add it to cart and continue shopping, we will confirm you the price shortly once you submit the order successfully.

Units Price per Unit (1 Unit = 1 PC)
above1Need to log in
Cobot:
920mm 1300mm 1500mm 1800mm
Power:
1500W 2000W 3000W

This item has been added to shopping cart.

View Shopping Cart  Continue Shopping

Groupbuy Wishlist

Lower Price, Buy Together. We will release the groupbuy for this item by collecting the information from your Groupbuy Wishlist and offer you an unbelievable price.

*

*

*



Operation of the machines


Key specifcaiton

Parameter Classification Parameter Name 920mm 1300/1500/1800
Mechanical Arm Parameters Maximum Working Radius (Arm) 920mm 1300/1500/1800mm
Repeat Positioning Accuracy ±0.03mm ±0.05mm
Maximum Tool - end Speed (Tool Max speed) 3000mm/s 4000mm/s
Control Bus/Frequency (ControlBus/Freq) EtherCAT/1KHz
Rated Power (Rated power) 550w 1500w
Operating Temperature Range (Temp) -5 - 55°C
Operating Humidity (Hum) 5% - 90%RH, non - condensing
Installation Mode (Installation mode) Arbitrary angle installation
Protection Degree IP65
Weight 21kg 22kg / 37kg / 39kg
Noise Level (Noise level) ≤60dB
Working Port Parameters I/O Port (I/O 口) 1 circuit of 24V/1A power supply; 2 DI; 2 DO; 2 AI
COM Port (COM 口) 1 circuit of 24V/1A power supply; 1 circuit of RS485; 1 circuit of EtherCAT
Joint Motion Parameters Motion Range - J1 -360° - 360° -360° - 360°
Motion Range - J2 -360° - 360° -360° - 360°
Motion Range - J3 -165° - 165° -165° - 165°
Motion Range - J4 -360° - 360° -360° - 360°
Motion Range - J5 -360° - 360° -360° - 360°
Motion Range - J6 -360° - 360° -360° - 360°
Maximum Speed - J1 150°/s 180°/s
Maximum Speed - J2 150°/s 180°/s
Maximum Speed - J3 210°/s 210°/s
Maximum Speed - J4 240°/s 270°/s
Maximum Speed - J5 240°/s 270°/s
Maximum Speed - J6 240°/s 270°/s
The Laser power source (1500w/ 2000w / 3000w ) is available.
