Specification
| Model | CH-60 | CH-70 | CH-80 | |
| Aperture(mm) | Φ10.5,Φ13.8,Φ17.5,Φ20.5 | Φ10.5,Φ13.8,Φ17.5,Φ20.5 | Φ16,Φ18,Φ22,Φ25 | |
| Output(Ton) | 31 | 35 | 50 | |
| Max thickness | Iron sheet | 6mm | 10mm | 16mm |
| Copper Busbar | 10mm | 12mm | 20mm | |
| Throat Depth(mm) | 95 | 110 | 115 | |
| Size(mm) | 350×245×110 | 370×240×150 | 400×260×160 | |
| Weight(kg) | 19 | 38 | 50 | |
| Standard dies(mm): Φ3/8"(10.5)Φ1/2"(13.8)Φ5/8"(17.5)Φ3/4"(20.5)×4Sets | ||||
| The non-standard dies are optional. And the Pumps are optioanl. | ||||
