Key Features
● Multi-function of Pulse MIG / MIG / MMA / TIG / Carbon Arc Gouging
● Full digital DSP control technology
● Online programming and software update
● Upto 100 sets of specialistic data base system realize welding parameter storage and call function
● With various of connectors ( optional) which can connect with the welding robot and special welding machine
Specification
|
Model |
MIG-280DP |
MIG-350DP | MIG-500DP |
|
Input |
220V/380V ± 10% |
380V ± 10% | 380V ± 10% |
|
Rated input capacity（ |
10 |
17 | 30 |
|
Current Range（A) |
15-280 |
18 -350 | 20-500 |
|
Voltage Range |
15-31 |
15-40 | 15-50 |
|
Duty Cycle |
60% |
60% | 60% |
|
Welding Wire(mm) |
0.8-1.2 |
0.8-1.6 | 0.8-1.6 |
| Cooling Method | Air cooling | Water cooling | Water cooling |
|
Weight (kg) |
72+ 15 kg |
85+ 15 kg | 110+ 15 kg |
|
Dimension (mm) |
995x225x960 |
1100x430x1500 | 1100x430x1500 |
Package: 1 wooden box+ 1 carton
