Key features
● It adopts lever pressurization or pedal control. Lever pressurization can make electrode move vertically.
● Upper and lower electrodes can be adjusted inclinedly and its electrode arms can make forward and backward movement.
● It adopts automatic control integrated circuit of precision numerical control electron for precise control of welding time.
● It is based on spot welding of low carbon steel, stainless steel and its pressing.
● Applicable to household electric appliance; Suitable for medium and small enterprises' sheet metal processing.
Specification
| Model | DNY-16 | DNY-25 | DNY-50 |
| Voltage/Frquency | 380V/50Hz | 380V/50Hz | 380V/50Hz |
| Rated Input Capacity(kva) | 16 | 25 | 50 |
| Duty Cycle(%) | 20 | 20 | 20 |
| No Load Voltage(V) | 2.3-8.8 | 2.8-10 | 4- 15 |
| Welding Time Adjust(s) | 0.02-1.98 | 0.02-1.98 | 0.02-1.98 |
| Water Flow(L/H) | 80 | 100 | 120 |
| Welding Thinkness(mm) | 1.0+1.0 | 1.5+1.5 | 2+2 |
| Dimension(mm) | 450*290*480 | 500*310*560 | 500*310*560 |
| N.W.(KGS) | 50 | 60 | 85 |
