Key features
● Precision CNC electronic automatic control integrated circuit is used to cotnrol the time and welding heat accurately
● With unique vertical design, no inclination occurs when electrode carries out pressing operation
● Foot press lever can be roated from 0°-180°, so the operation can be done in any position.
Specification
| Model | DN-16 | DN-25 | DN-35 |
| Input Voltage/Frequency | 1～380V 50/60Hz | ||
| Rated input capacity | 16KVA | 25KVA | 35KVA |
| Rated primary current | 42A | 63A | 92A |
| Non-load Voltage(V) | 1.98-3.01 | 2.25-3.58 | 3.1-5.2 |
| Electrode arm length | 290mm | 290mm | 290mm |
| Welding plate thickness | ≤2+2 | ≤2.5+2.5 | ≤3+3 |
| Duty cycle | 20% | 20% | 20% |
| Weight | 85kg | 105kg | 110kg |
