Key Features
·New type holster, streamline design.
·Large LCD makes the reading clearly.
·Metallic screen board with stronger antimagnetic and anti-interferential function.
·Full function protection, anti-high voltage circuit design.
Specifications
|
Basic Function |
Range |
Basic accuracy |
|
DC Voltage |
200mV/2V/20V/200V/1000V |
±(0.5%+3) |
|
AC Voltage |
2V/20V/200V/750V |
±(0.8%+5) |
|
DC Current |
20uA/2mA/200mA/ |
±(0.8%+10) |
|
200uA/20mA/200mA/ |
|
|
|
AC Current |
2mA/200mA/ |
±(1.0%+15) |
|
20mA/200mA/ |
|
|
|
Resistance |
200Ω/2kΩ/20kΩ/200kΩ /2MΩ/20MΩ |
±(0.8%+3) |
|
200Ω/2kΩ/20kΩ/200kΩ/20MΩ |
|
|
|
Capacitance |
20nF/2uF/200uF |
±(2.5%+20) |
|
Celsius |
(-40~1000)℃ |
|
|
Special Function |
|
|
Diode |
√ |
|
Transistor |
√ |
|
Continuity buzzer |
√ |
|
Low battery indication |
√ |
|
Data Hold |
√ |
|
Auto power off |
√ |
|
Function protection |
√ |
|
Restorable fuse protection |
√ |
|
Shockproof protection |
√ |
|
Input impedance |
10МΩ |
|
Sampling rate |
3 times/s |
|
AC Frequency response |
40~400Hz |
|
Operation way |
Manual range |
|
Max. Display |
1999 |
|
LCD size |
55× |
|
|
9V ( |
|
Product color |
Case: dark gray; Holster color：yellow |
|
Product Net Weight |
Approx: |
|
Product Dimension |
168×87× |
|
Standard Accessories |
Test leads、battery、instruction manual、TP01 |
|
temperature probe（with temperature function）、Testing accessories |
|
|
Standard inner packing |
Color box |
|
Standard Quantity Per Carton |
30 pcs |
|
Carton size |
405×350× |
|
Standard Gross Weight |
Approx: |
