Key Features
● Continuously variable control for Shade, Sensitivity and Delay time in your preference;
● Outside knobs make your operation easily and confortable.
● "Welding"/"Grinding" can be selective by switch. The Grind mode, great for weld prep or post-weld clean up activities;
● Solar powered, with Li-Battery Assist;
● Large Viewing area 98*62mm,not 92*42mm.
● The other color is optional
● ANSI,CAN/CSA and CE approved
Specification
|
Model |
YC-09 |
|
Viewing Area |
98×62mm |
|
Optical Class |
1/1/1/2 |
|
Cartridge Size |
110×90×9mm |
|
Light State |
DIN 4 |
|
Dark State |
Variable shade, 9 ~13 for welding Variable shade, 5 ~8 for grinding |
|
Shade Control |
External,Variable |
|
Power On/Off |
Fully Automatic |
|
Arc Sensor |
4pcs |
|
Sensitivity |
Yes |
|
UV/IR Protection |
DIN16 |
|
Power Supply |
Solar cell & Lithium Battery |
|
Switching Time |
1/25000S, from Light to Dark |
|
Dark to Light |
0.1-1.0S |
|
Low Amperage TIG |
≥5amps(DC),≥5amps(AC) |
|
Grinding Function |
YES |
|
Low Volume Alarm |
YES |
|
ADF self-check |
YES |
|
Operating Tep. |
-5℃~+55℃ |
|
Storing Tep. |
-20℃~+70℃ |
|
Ship Dimension |
300x240x250mm |
|
Ship Weight |
0.85kg |
