Key Features
● One set,dual function, this one is the advanced product with dual function -generating and welding,.The unit can achieve perfect waveform of the welding voltage,no-fluctuating welding current realize high quality welding operation. The welding arc is super smooth to get the perfect welding quality.Furthermore,its welding current regulation is wide enough to suit most of weld.
● High Quality with CE Approved.
● Longer service life.
Specification
| Model No. BT6500DGW | ||
| Generator | Rated frequency[Hz] | 50/60 |
| Rated voltage[V] | 110/120/220/230/240 | |
| Rated output power[KVA] | 4.0/4.2 | |
| Rated rotation speed[rpm] | 3000/3600 | |
| Phase number | Single phase | |
| Structure type | Open-frame | |
| Starting system | CL:recoil start E:electric start | |
| Power factor[cosφ | 1.0 | |
| Welder | Rated welding DC current(A) | 180 |
| Rated welding work voltage(V) | 26 | |
| Welding load continuous ratio | 40% | |
| Current regulation range(A) | 50-180 | |
| Welding load continous rate(%) | 12 hours | |
Engine |
Engine Model | BT186F/E |
| Engine Type | Single cylinder,4-stroke,air-cooled,irect injection, diesel engine | |
| Rated power[KW(Hp)/rpm] | 3.7(5.0)/3000 4.0(5.5)/3600 | |
| Fuel | 0#(summer) or 10#(winter)-20#(chillness) diesel | |
| Lube | CDgrade or SAE 10W-30,15W-40 | |
| Fuel tank Capacity (L[gal] | 12.5(2.75) | |
| Packing | Net weight [kg(lbs)] | 121 |
| Overall dimension [mm(in)](L×W×H) | 740x500x670 | |
There are currently no optional accessories for this item.
