Key Features
● The device is based on the basic principle of the milling cutter installed on the use of different materials carbide
Tools for milling. It performs a good surface finish and the surface roughness is Ra3.0-12.
● Can bevel the stainless steel, carbon steel plate .
● Easy to operate and low price.
● It performs the high quality beveling work.
● If the plate is short, then you can fix the beveling machine and the plate will be automatically feeding and beveling. If the plate is long, then you can fix the plate, and move the beveling machine to bevel the plate.
Specification
| Model | XB-900 |
| Input Voltage（Main motor) | 380V |
| Rated Power(Main motor) | 2*2.2KW |
| No-load speed(Main motor) | 1410RPM |
| Input Voltage（Feed motor) | 380V/220V |
| Rated Power(Feed motor) | 200W |
| No-load speed(Feed motor) | 1380RPM |
| Max. Bevel Width(W) | max 15mm/single working (can be adjustable) |
| Beveling Width | 0-46mm |
| Beveling Angle(α) | 25°-60° |
| Beveling Speed | 0-1.0m/min |
| Plate Thickness(T) | 5-60mm |
| Beveling surface finish | Ra3.0-12 |
