Key Feature
● Stable arc.
● Low splashing.
● High deposited effeciency.
● Suitable for all position.
Specification
Typical Chemical Composition of Deposited Metal(%)，AWS ER70S-6 (GB ER50-6)
| C | Mn | Si | Cr | Ni | Mo | Cu | S | P | V | |
| Typical | 0.07 | 1.47 | 0.90 | 0.020 | 0.021 | 0.007 | 0.18 | 0.011 | 0.012 | 0.008 |
Typical Mechanical Properties of Deposited Metal，AWS ER70S-6 (GB ER50-6)
| Tensile Strength бb(MPa) | Elongation δ5(%) | Yield pointбb(MPa) | Impact Value(J) | ||
| -30℃ | 160 | ||||
| Typical | 550 | 29 | 450 | -- | -- |
Size, Packing, AWS ER70S-6 (GB ER50-6)
| Size(mm) | ф1.6 | ф2.0 | ф2.5 | ф3.2 | |
| Packing | 1meter/pc, 10kg/box | ||||
Note: 1unit=1kg
