Products information
AWS E6013 (GB E4313) is carbon steel welding electrode covered with a high titania potassium type coating. Both AC and DC can be applied, and it is applicable for all-position welding, including vertical-down welding. It shows a very good welding performance with small spatters, easy restrike arc and very good wled shape.Suitable for welding low carbon steel structures and low carbon galvanized plate especially applicable for vertical-down welding and intermittent welding.
Chemical Composition of Deposited Metal(%)，AWS E6013 (GB E4313)
| C | Mn | Si | S | P | |
| Standard | -- | -- | -- | ≤0.035 | ≤0.040 |
Mechanical Properties of Deposited Metal，AWS E6013 (GB E4313)
|
Yield pointбb(MPa)
|
Tensile Strength бb(MPa) | Elongation δ5(%) | |
| Standard | ≥330 | ≥420 | ≥17 |
Sizes, packing & Recommended Current(AC or DC), AWS E6013 (GB E4313)
| Size(mm) | ф2.5×350 | ф3.2×350 | ф4.0×400 | ф5.0×400 | |
| Current(A) | 60-100 | 80-150 | 160-200 | ||
| Packing | 5kg/box, 20kg/carton | ||||
Feature picture
There are currently no optional accessories for this item.
