Key Features
Thorium-Tungsten Electrode is widely used as an additive oxide electrode ,having much more advanced comprehensive welding performance than the properties of Pure Tungsten Electrode and other additive oxide electrodes. It can not be replaced by other oxide electrodes during the long use process. It can be operated easily has a high current load and produce arc easily and steadily. In addition, the gap of the breaking arc is big ,loss less and life longer .It has higher re-crystallized temperature, better conductivity and mechanical cutting property .Now, Thorium-Tungsten Electrode is wildly used in welding carbon steel, stainless steel, nickel alloy and titanium metal. It becomes the first selection material for high quality welding.
Model specification
| Model | Oxide Addictive |
Oxide Addictive content% |
Impurities content% | The remainder | Color standard |
| WT20 | THO2 | 1.80-2.20 | <0.2 | Tungsten | Red |
Other information
| Material | Diameter(mm) | Length(mm) | Surface | Packing |
| Thorium-Tungsten ecletrode |
1.0 | 150 / 175 |
Polish |
10pcs/box, 1600pcs/carton |
| 1.6 | 10pcs/box, 1600pcs/carton | |||
| 2.0 | 10pcs/box, 1600pcs/carton | |||
| 2.4 | 10pcs/box, 800pcs/carton | |||
| 3.2 | 10pcs/box, 800pcs/carton | |||
| 4.0 | 10pcs/box, 400pcs/carton | |||
| 4.8 | 5pcs/box, 400pcs/carton | |||
| 6.0 | 5pcs/box, 400pcs/carton |
Note: 1unit=1pc
