Key Features
● Super Silent.
● Factory direct price.
● Digital.
● A full tank of fuel can last for 4 constant hour.
● Certificates:GS/CE,EMC,Noise,O2,EPA,CARB,popular in America and Europe
Product Description
● Max. output power is 1.0kVA.
● Low noise design, 53-59 dB(A)/7m.
● Lightweight and compact, only 16 kg.
● A full tank of fuel can last for 4 constant hours.
● Advanced inverter technology provides reliable power to computers and other sensitive equipments.
● Certificates:GS/CE,EMC,Noise,O2,EPA,CARB.
Specification
| Model | GI1000 European Type | GI1000 American Type |
| Rated frequency (Hz) | 50 | 60 |
| Rated voltage(V) | 230 | 120 |
| Rated current(A) | 3.9 | 7.5 |
| Rated speed (r/min) | 5500 | 5500 |
| Rated output (kVA) | 0.9 | 0.9 |
| Max. output (kVA) | 1 | 1 |
| DC output | 12V-5.0A | 12V-5.0A |
| Phase number | Single | Single |
| Current breaker | YES | YES |
| Structure type | Portable, silent | Portable, silent |
| Fuel capacity(L) | 3.2 | 3.2 |
| Set fuel consumption(g/kW.h) | 420 | 420 |
| Continous running time(hr)(rated output) | 3 | 3 |
| Noise level(zero load-full load)dB(A)/7m | 53-59 | 53-59 |
| Overall dimension(L×W×H)(mm) | 510X270X440 | 510X270X440 |
| Net weight(kg) | 16 | 16 |
| Starting system | Recoil starter | Recoil starter |
| Fuel type | Automotive unleaded gasoline | Automotive unleaded gasoline |
| Engine Model | GY144 | GY144 |
| Engine Type | Single cylinder, four-stroke, OHV,vertical, air-cooled | Single cylinder, four-stroke, OHV,vertical, air-cooled |
| Bore×stroke (mm) | 43.5×36 | 43.5×36 |
| Displacement (ml) | 53.5 | 53.5 |
| Compression ratio | 8.5:1 | 8.5:1 |
| Rated power[Kw(r/min)] | 1.15/5500 | 1.15/5500 |
| Ignition system | C.D.I | C.D.I |
| Spark plug | A7RTC | A7RTC |
| Lowest fuel consumption(g/kW.h) | 420 | 420 |
